HT Pipe Bend DN/OD 110 30 Degree - Waste Water Solution

Yes, the HTsafeB pipe system is also approved for central vacuum systems. Its high abrasion and impact resistance make it very durable and safe for this application.

Yes, you can cut the HTsafeB pipes with a metal or fine saw to the desired length. It is important that the saw edges are cleanly beveled and any burrs are removed afterward. This protects the seals and ensures a proper connection.

Yes, you can make a 90-degree change in direction using multiple 30-degree bends. Always ensure the prescribed minimum gradient of 2 cm per meter to avoid blockages and deposits. The HTsafeB system ensures optimal hydraulics and self-cleaning.

Yes, this HT Bogen and the entire pipe system are known for their optimal noise behavior and excellent sound insulation. The material polypropylene and the construction contribute to significantly reducing the flow noise.

The HT bend with 30 degrees is designed for directional changes within household drainage. When transitioning from vertical to horizontal pipes, it is important to avoid blockages and maintain the minimum gradient of 2 cm per meter.

Yes, the installation of the HTsafeB system is very easy and quick thanks to the plug connections. The beveled pipe end is simply inserted. Pay attention to the centimeter marking and pull the pipe out one centimeter after assembly for length compensation.

Yes, the HTsafeB pipe system shows robust behavior under mechanical stress, such as high-pressure flushing. The smooth surfaces and self-cleaning properties of polypropylene also reduce the tendency for deposits and incrustations.

Yes, it is important to pull the pipe out one centimeter after fully assembling it. This creates an effective length compensation, which is essential for the long-term stability and functionality of the system.

No, the HTsafeB system offers optimal noise behavior and very good sound insulation. You will perceive the noise from the wastewater significantly less than with conventional systems.

Yes, the bend is made of polypropylene and is specially designed to withstand hot water. The temperature range is between -20° and 90°, so hot wastewater from dishwashers or washing machines can be drained without any problems.

Thanks to the smooth surfaces and optimal hydraulics, the HTsafeB system has minimal tendency to incrustation or deposits. It is self-cleaning, leading to long maintenance intervals. Regular manual cleaning is therefore rarely necessary.

The HTsafeB pipe system is designed for drainage inside buildings and is suitable for temperatures from -20° to 90° C. It is not primarily designed for permanent outdoor use or areas exposed to severe, unprotected frost.

The HTsafeB bow is characterized by high chemical resistance and is stable in the pH range of 2 to 12 (acidic to basic). It is thus resistant to common household cleaners and also to biogenic sulfuric acid corrosion.

The HTsafeB system provides a secure seal thanks to the patented triple sealing lip and the replaceable NBR seal. In combination with our safety devices, the system is approved for a maximum pressure of 2.0 bar, ensuring high operational safety.
