89mm Pipe Insulation, 2m Rubber Heating Pipe Insulation

The pipe insulation is designed for a temperature range of up to +110 °C. It is not suitable for higher peak temperatures, such as those that can occur in solar thermal systems.

The specified insulation thickness of 40 mm actually corresponds to 44 mm after the GEG adjustment. This thickness is GEG-compliant for pipes with an outer diameter of 89 mm.

One rod of the pipe insulation is 2 meters long. For 6 meters of pipe, you therefore need 3 rods of the material. (roughly calculated: That corresponds to 3 rods of 2 meters).

For 15 meters of heating pipe, you need 8 rods of insulation (roughly calculated: 15m / 2m per rod = 7.5 rods, rounded up to 8). For the proper sealing of joints and seams, you need a suitable rubber adhesive.

Yes, the insulation is specially designed for pipes with an outer diameter of 89 mm. It encloses them exactly.

Yes, the product is approved for hot water pipes in sanitary areas according to GEG. It withstands temperatures up to +110 °C and meets the requirements.

The insulation offers an insulation thickness of 44 mm and meets the GEG requirements for minimizing heat loss. It is therefore well suited for the attic area, provided the pipes have an outer diameter of 89 mm.

The pipe insulation is supplied in 2m rods. For a permanent and tight installation, it is recommended to glue the joints and longitudinal cuts with a suitable rubber adhesive.

Yes, the pipe insulation is designed for temperature applications up to +110 °C. It is therefore very suitable for heating pipes.

The insulation is primarily intended for heating and sanitary areas as well as cold water pipes indoors. For permanent use in unprotected outdoor areas, an additional UV protection layer is recommended.

The INSUL-TUBE® H PLUS is primarily designed as thermal insulation for heating and cold water pipes. A specific suitability for noise reduction on ventilation ducts is not specified.

Yes, the closed-cell material is also suitable for cold water pipes according to DIN 1988 200 and reliably prevents the formation of condensation.

The product is intended for pipes with an outer diameter of 89 mm. At 90 mm, the fit may be very tight or make an exact seal difficult.

With an actual insulation thickness of 44 mm (formerly 40 mm), the fire behavior falls into Euroclass CLs3d0. This is valid for insulation thicknesses of 30-45 mm.

The insulation is optimized for a pipe diameter of 89 mm. With an 87 mm pipe, there may be a slightly looser fit, which could minimally affect the insulation effect.

Yes, the insulation thicknesses of this pipe insulation are designed according to the current GEG specifications. The actual insulation thickness of 44 mm meets the requirements.

The temperature range for this pipe insulation is up to +110 °C. At temperatures above this value, material damage can occur.

One rod of the insulation has a length of 2 meters. For longer distances you will need several rods accordingly, which you can simply join together.

The insulation is suitable for heating pipes with the appropriate outer diameter (89 mm). For the direct connection of a heating pump, you should check the specific diameters.

A rod of the pipe insulation is 2 meters long. The product is also suitable for cold water pipes to effectively prevent condensation (sweating).

The insulation is resistant to aging, which also concerns the color stability. It is designed for permanent insulation in various environments and retains its appearance.

The insulation prevents frost damage to water pipes thanks to its excellent thermal conductivity and optimal thermal insulation of 0.034 W/mK at 0 °C.

The insulation is made of soft foam based on synthetic rubber and is very easy to work with. A normal, sharp utility knife is perfectly adequate for a clean cut.

The closed-cell structure of the insulation material effectively prevents moisture absorption and condensation. This reliably protects against mold and corrosion damage, even in more humid environments.

Yes, the insulation is flexible and adapts well. This flexibility also makes installation easier on uneven surfaces or curves.

The roll should be stored away from sunlight. The product description does not provide specific information on UV resistance for permanent use outdoors.

The insulation is specifically intended for heating, hot water and cooling systems and is not explicitly designated for waste water pipes. One roll of the AEROFLEX® SH XT has a length of 2 meters.

The black design of the pipe insulation was deliberately chosen to reduce visual disturbances. It offers an unobtrusive and professional look for various environments.

Each roll of AEROFLEX® SH XT pipe insulation has a length of 2 meters. The product is only available in black.

No, the pipe insulation is self-adhesive on the back and adheres firmly to metallic surfaces. If necessary, you can additionally secure the longitudinal sides with adhesive tape to ensure optimal tightness.
