Malleable Iron Pipe Fitting, 1/2" Threaded Nipple, Galvanized

The sleeve nipple is suitable for gas station construction as well as conveying liquids and gases. Ensure compliance with the maximum permissible operating pressures and temperatures. Proper sealing of the threads is essential.

The socket nipple is galvanized, providing good corrosion protection. It can therefore be used in the basement for water pipes, as long as the temperature limits are observed.

Yes, the socket nipple is suitable for heating installations. The maximum operating temperature is 120°C at 25 bar, which allows use with 100°C hot water. Proper thread sealing is essential here.

The threads are standardized according to ISO 7-1/EN 10226-1, which ensures a standardized connection. To seal the non-self-sealing threads, you should use PTFE thread seal tape or thread seal hemp.

The nipple is not self-sealing. For sealing, you should use suitable thread sealant material such as PTFE thread seal tape (Teflon tape) or thread seal hemp.

Yes, the coupling is approved for a maximum operating pressure of 25 bar at temperatures up to 120°C. So 10 bar is not a problem.

Yes, the threaded fitting is DVGW-approved and suitable for gas installations. Proper sealing is mandatory.

The nipple is not self-sealing. You can safely use Teflon tape (PTFE thread seal tape) or thread seal hemp, they are designed for this.

Yes, the nipple is suitable for the installation of liquids, such as water, and has 1/2" internal and external threads. Since the threaded connections are not self-sealing, you will need a suitable sealing material such as PTFE sealing tape or sealing hemp.

The socket can be used up to 300°C at a maximum operating pressure of 20 bar. Therefore, it is suitable for steam applications up to 150°C, pay attention to the corresponding pressure.

Yes, the coupling is suitable for cold water pipes. The allowable temperature range is between -20 °C and 300 °C, making it usable for frost outdoors as well.

Yes, the threaded fitting has DVGW approval and meets the UBA METALLE standard. It is therefore suitable for drinking water installations.

The socket nipple made of malleable cast iron has a tensile strength of < 350 N/mm² and is designed for use in mechanical engineering. It is therefore suitable for typical light mechanical loads in these applications.

The combination of tapered external thread and parallel internal thread is standardized. Use suitable thread sealing material such as PTFE tape or thread sealing hemp.

No, the thread forms are different. The external thread is conical/tapered, while the internal thread is parallel/cylindrical.

Yes, the double nipple is approved for these conditions. At operating temperatures up to 300°C, the maximum allowable operating pressure is 20 bar, so your system pressure of 15 bar is covered.

The external thread of this fitting is tapered. The internal thread is parallel/cylindrical.

Yes, the nipple is approved for use in commercial vehicles and petrol stations. The application for fluids such as diesel or hydraulic oil within the specified temperature and pressure range is safe.

Yes, the threaded fitting has the necessary DVGW approval and meets the UBA METALLE standard, making it suitable for drinking water installations.

The hose nipple is designed for operating temperatures up to -20°C. As long as the temperature does not drop below that, use in winter is possible.

Yes, the threads of the socket nipple are manufactured according to ISO 7-1/EN 10226-1. This ensures compatibility with other standardized pipe connections and fittings.

Yes, the socket nipple is made of cast iron. Cast iron is a magnetic material.

The tapered shape of the external thread supports the screwing and sealing effect. When sealing with hemp or PTFE tape, it is important that the sealing material is applied evenly and sufficiently to the thread to ensure a reliable seal.

No, the threaded connections are not self-sealing. You should use a suitable material like Teflon tape or hemp for sealing.

Yes, the socket nipple is galvanized, which protects it from corrosion. It is designed for heating installations and can be used in humid environments.

The threads are manufactured according to common standards ISO 7-1/EN 10226-1 and correspond to the Whitworth pipe thread. This is a standard size used for water pipes.

The socket nipple is galvanized, which provides corrosion protection. This makes it suitable for humid environments, such as basements.

Yes, the socket nipple is approved for use in gas installations and pressures up to 25 bar at 120°C. Therefore, it is suitable for your application.

Yes, the socket nipple made of tempered cast iron is approved for temperatures up to 300°C at an operating pressure of 20 bar. It is therefore significantly more suitable for hot steam pipes than plastic fittings.

The threaded fitting is designed for a maximum allowable operating pressure of 25 bar at temperatures up to 120°C. It will therefore permanently withstand the mentioned load.
