Brown 67.5° Gutter Elbow for System 90

Yes, the bend is part of the System 90, which is intended for downpipes with a diameter of 90mm. This system is ideal for single-family homes as well as small and medium-sized storage buildings.

A fine-tooth saw is recommended for cutting the gutters and downpipes of the system, which includes this bend. A straight cut at a right angle is important for the fit.

No, this elbow is intended for a downpipe with a diameter of 90mm (System 90). For the 75 system, a downpipe with a diameter of 63mm is used.

This bend is primarily designed as a downpipe bend for vertical rainwater drainage. There are other fittings for horizontal lines in the gutter system.

This bend is intended for the 90 system. It therefore fits downpipes with a diameter of 90mm.

This bend is in the color brown (RAL 8017). For gray downpipes, a bend in graphite (RAL 7021) from the BRYZA system would be suitable to ensure a uniform appearance.

The bend is designed for a downpipe with a diameter of 90mm (system 90). If your cistern has a suitable connection for 90mm downpipes, this bend can be used without any problems.

Yes, the downpipe bend can be used to direct the rainwater in the desired direction to a collection tank. It is part of the complete gutter system for effective water drainage.

The bend offers a fixed angle of 67.5°. For flexible angle adjustments, especially with dormers, the BRYZA system offers adjustable corner pieces for gutters, but not adjustable downpipe bends.

The bend is intended for the 90 system of the BRYZA downpipe system. This downpipe system is used for the 100mm (with 90mm downpipe) and 125mm (with 90mm downpipe) gutter systems.

The bracket spacing for the downpipe brackets should generally be 40-50 cm. This also applies in the area of bends to ensure a stable fastening.

This elbow is brown (RAL 8017). It fits the dimensions of gray downpipes of the 90mm system, but there would be a color difference.

Yes, the color of this arch corresponds exactly to brown (RAL 8017). This ensures a uniform appearance throughout the BRYZA system.

The arch is part of the BRYZA gutter system and was developed for its specific dimensions and connection types. Compatibility with other manufacturer systems cannot be guaranteed.

The BRYZA gutter system is designed for easy installation. With a fine-tooth saw for cutting and observing the assembly instructions, self-assembly is easily doable for experienced DIYers.

Yes, the connection types of the BRYZA gutter system are specially designed to compensate for thermal length changes of the system parts. This ensures permanent stability and tightness during temperature fluctuations.

To bridge a wall distance, two bends of the 67.5° or 90° type (not this article) are usually required to create an offset and guide the downpipe parallel to the wall again.

Yes, the bend is designed for downpipes with a diameter of 90mm in the 90 system. The gutters of the 125 system also use downpipes with a diameter of 90mm and are therefore compatible.

Yes, downpipes should be cut at right angles with a fine-tooth saw for a clean connection with the bend. This ensures a precise fit.

This bend is part of the BRYZA gutter system and is designed for downpipes with a diameter of 90mm. The connection to downpipes is made via special connecting sleeves of this system. Compatibility with foreign systems or metal pipes cannot be guaranteed.

The connection of the downpipes with the pipe fittings is made via connecting sleeves without additional sealing. The system is designed to ensure tightness and compensate for thermal length changes.

No, this bend is designed for the 90mm downpipe system. The 75 gutter system uses a downpipe with a diameter of 63mm.

The BRYZA gutter system is an established product whose materials are designed for the usual weather conditions outdoors. The thermal length compensation function helps to avoid material stresses during temperature fluctuations.

The connection of downpipes with pipe fittings like this arch is done with connecting sleeves without additional sealing. A snap connection with a rubber profile is provided for gutter fittings.

Yes, the bend is part of the 90mm downpipe system, which is recommended for the 100mm and 125mm gutter systems. These systems are also suitable for commercial and industrial buildings as well as public buildings.

Make sure that the gutter to which the downpipe leads has a slope of 2mm per meter in the direction of the spigot. This ensures optimal water drainage through the downpipe system.

The 90mm downpipe system is recommended for single-family homes, small and medium-sized warehouse buildings, as well as commercial and industrial buildings. It is also suitable for public buildings.

Yes, the type of connection of the gutter system parts, including the downpipe arches, is designed to compensate for thermal changes in length. This contributes to the frost resistance of the system.

Yes, the 67.5° bend is designed for the 90mm downpipe of the 90 system. This downpipe is also combined with the 125 gutter system.

The assembly is basically possible even in light rain. However, for a correct and secure connection, the parts should be clean and dry to ensure optimal sealing.
