PPSU Press Fitting T-Stück - 20mm Tee Connector

The T-piece is made of high-performance plastic PPSU, which is 100% lead-free and highly resistant. It is shatterproof, durable, and therefore ideal for drinking water installations.

Yes, the T-piece has three inspection windows in the stainless steel sleeve. These allow easy visual verification that the pipe has been inserted to the correct depth.

The two o-rings are designed for optimal security. They ensure increased tightness and reliability of the press connection under operating conditions.

The PPSU Pressfitting is designed for a durability of 50 years at 10 bar and 70° C. The construction with two O-rings and a stable guide ring ensures high safety.

Yes, the PPSU t-piece is flow-optimized and causes almost no noise. This allows for an undisturbed installation even in walls.

Yes, this PPSU Pressfitting is 100% lead-free, as it is made from high-performance plastic (polyphenylsulfone). All materials are safe for use in drinking water and are DVGW-certified.

This PPSU pressfitting t-piece is specifically designed for 26mm pipe diameter. For other diameters or reductions, you need the corresponding fittings.

Using composite pipes other than those sold by Boni-Shop is at your own risk. Compliance with regulations is only guaranteed with system-approved components.

Yes, the installation manual requires that the pipe end be calibrated and deburred after cutting. This is crucial for a correct and tight connection.

The T-piece is designed for a durability of 50 years at up to 70°C. The maximum operating temperature is 95°C, but not for a 50-year durability in this temperature range.

Yes, the system is designed so that uncompressed connections can be located during the pressure test. This applies to dimensions 16-32 mm.

Yes, the PPSU Pressfitting T-piece is ideal for use in heating systems, including underfloor heating. It is suitable for high temperatures up to 95°C.

Yes, the stable plastic guide ring ensures secure crimping, even in tight spots. Additionally, the three inspection windows in the stainless steel sleeve help verify the correct insertion depth.

Yes, the three inspection windows in the stainless steel press sleeve serve to visually check the correct pipe insertion depth. They ensure the pipe is inserted deep enough.

You need a press jaw with a TH contour that matches the fitting dimensions. Using unsuitable press jaws can compromise the seal of the connection.

Yes, the T-piece is flow-optimized and has a free passage. This results in a very good resistance coefficient and virtually no flow noises in the system.

The T-piece is designed for a maximum operating temperature of 95° C. The long-term durability is 70° C for over 50 years.

Yes, this T-piece is DVGW-certified (DW-8501BS5049) and meets the requirements of the UBA positive list, making it safe for drinking water installations. It is also 100% lead-free.

For installation, you will need a suitable pressing tool and a pressing jaw that matches the fitting's dimensions. Additionally, a calibrator and a deburring tool for the pipe end are required.

Yes, the integrated stable plastic guide ring ensures secure pressing. It ensures a stable hold of the pipe even in forced positions during installation.
