Pressfitting Ball Valve Green Wing Handle 16 x 2

Yes, the ball valve has a plastic guide ring that ensures precise positioning in the press jaw even in tight spaces. This allows for secure pressing.

Yes, the ball valve is suitable for hot water. The long-term durability is up to 70°C, the maximum operating temperature is up to 95°C.

Yes, the correct insertion depth of the pipe is clearly visible through three integrated inspection windows in the stainless steel press sleeve. This provides you with an important safety advantage during installation.

The ball valve is designed for continuous use at 70°C. However, the maximum operating temperature is 95°C, so temporary use at this temperature is possible.

The ball valve is designed for a durability of 50 years at 10 bar and 70° C. This ensures a long lifespan in your installation.

The ball valve features a modern, flow-optimized contour with free passage. This results in virtually no flow noise and the best ZETA values.

This press fitting is leaky when unpressed, which is a safety feature. After correct pressing, a void-free connection with two O-rings is created for the highest safety and tightness.

The red color of the handle serves solely for visual identification. It has no impact on the technical function or operation of the valve BONI-P62KU16.

A compliant connection exists only with system-approved components in all press systems. The use of other connecting pipes than those sold by Boni-Shop is at your own risk.

For the 16mm ball valve, press jaws with TH or U contour are suitable. The system is fully multi-contour compatible and offers flexibility in tool selection.

Yes, the ball valve features a new, flow-optimized contour. This ensures free passage and virtually no flow noise in the piping system.

The ball valve is fully suitable for drinking water and designed for operating temperatures up to 95°C. Permanent installation outdoors with risk of frost is not recommended, as functional safety could be affected.

Special maintenance of the ball valve is not required. Its long-term durability of 50 years and high-quality, lead-free material selection ensure low maintenance and long service life.

The ball valve is designed for a maximum operating temperature of 95° C. The permanent load capacity is 70° C and 10 bar for over 50 years.

No, the ball valve is 'unpressed and leaky'. A tightness test is only possible after proper pressing with the appropriate pressing tool.

Yes, the pipe end must absolutely be calibrated and deburred after cutting. This is an important step for a safe and tight connection.

Yes, the ball valve is designed for long-term use and is durable. The robust red brass construction and stable wing handle ensure reliable function even with frequent operation.

Yes, the designation 'Made in Germany' in conjunction with DVGW certification and the UBA positive list confirms that all components are low in lead or lead-free. The ball valve thus meets the requirements of the Drinking Water Ordinance.

Yes, the ball valve is fully suitable for drinking water. It complies with the UBA positive list and is DVGW-certified (DW-8501BS5049), also low in lead or lead-free.

Yes, this ball valve is flow-optimized and offers the best ZETA values with the largest flow area. It allows free passage and thus maximum flow with virtually no flow noise.

Yes, the integrated plastic guide ring allows secure anchoring even in confined spaces. The fitting's design supports precise installation under difficult conditions.

This press fitting (20x2 mm) is multi-contour compatible and can be processed with both TH and U press jaws. A suitable press tool is required.

The long-term durability for 50 years is specified at 10 bar and 70°C. With regular temperatures around 85°C, which are close to the maximum of 95°C, the lifespan of the fitting may be reduced.

The integrated inspection window in the stainless steel sleeve indicates the correct insertion depth of the pipe. This is a safety plus for the user.

The inspection windows serve as an important safety feature during installation. They allow visual verification that the pipe has reached the correct insertion depth in the press fitting before you press.

Yes, the plastic guide ring ensures secure compression even in difficult or tight areas by stabilizing the pipe.

It is recommended to use the composite pipes sold by Boni-Shop. Using other pipes is at your own risk and may affect system compliance.

This press fitting is designed for multilayer composite and copper pipes. Connection with old lead pipes is not intended and is not DVGW certified.

Yes, the integrated plastic guide ring ensures precise guidance of the pipe in the pressing jaw. This allows safe pressing even in tight spaces or awkward positions.

The ball valve is uncompressed and leaky, so proper compression is essential for tightness. The void-free connection with two O-rings ensures the highest safety.
