Sat flat antenna with single LNB
About this item:
- Flat satellite dish with integrated LNB
- reception performance comparable to a 60 cm parabolic dish
- ideal for mobile use
- HD/UHD reception
- new mounting system including window mount
| Item number | WF-600332 |
| Brand | Selfsat |
There are no reviews yet — yours could be the first
Share your experience with this purchase and help other customers make the right choiceThere are no questions yet
Ask a question to learn more about the product
0.0
- Compact and slim: flat satellite antenna with integrated LNB
- Efficient = reception performance like a 60 cm parabolic dish
- Versatile = Adaptable and adaptable to the design of your home
- Simple = Simple and easy installation
- Ideal for mobile use
- Mobile and universally applicable
- Aesthetic design for homes in town and country
- Discreet installation
- Reception of all major satellites
- Ideal for HD/UHD reception
- New mounting system including window mount (exclusive to the + series) for even better alignment of the satellite antenna
The reception performance of this flat satellite antenna corresponds to that of a high-quality 60 cm satellite dish and is ideal for all satellites such as Astra 19.2° East, Eutelsat 13° East, Sirius, etc. suitable.
The new Selfsat H22D+ series has an additional window mount compared to the normal H22D series.
The new Selfsat H22D+ series offers even better reception performance than the H30D/H30D+. Furthermore, the H22D+ has a replaceable LNB. This means you can easily replace the LNB in the event of a defect without having to buy a completely new satellite antenna. Furthermore, the H22D+ series can be adapted to current reception needs at any time, e.g. by easily replacing the Twin LNB with a Single, Quad or Quattro LNB.
Technical details:
- Frequency: 10.7 ~ 12.75 GHz
- Polarization: Vertical & Horizontal
- Reception power: 34.5 dBi @ 12.7 GHz
- LNB frequency: 950 - 1,950 / 1,100 - 2,150 MHz
- Operating temperature: -30°C ~ +60°C
- Weight: 4.9 kg
- Current consumption: 150mA (max)
- Operating temperature: -30°C to +60°C
- Storage temperature: -40°C to +80°C
- LNB output: LNB exchangeable (Single / Twin / quad)
- Switching Low / High: 0 KHz / 22 KHz
- LNB output frequencies: 950 - 2,150 MHz
- L.O. Frequencies: 9.75 GHz / 10.6 GHz
- LNB volume at 25°C: 0.2 dB typically
- Input VSWR: 2.5:1 typically
- Output VSWR: 2.5:1 typically
- Conversion Gain: 60 dB Typical
- Gain flatness: 6 dB p-p (max)
- Power supply: 12-14V DC (vertical) / 16-19V DV (horizontal)
Dimensions: (L x W x H): 566 x 300 x 78 mm
Included in delivery: Selfsat H22D+ flat antenna with single LNB, mast mount with fastening clamp, window mount, wall mount, stand, assembly instructions, Screw set, tool
| External dimensions | |
|---|---|
| External dimensions | 566 x 300 x 78 mm |
