• Vertical design for splitting short and meter-long wood - 1100 mm
• Operation only via PTO shaft
• Combination 3-point suspension
• Stable, torsion-resistant steel construction
• Fast operation thanks to continuously adjustable splitting stroke
• State-of-the-art safety operation according to the new 2017 standard
• Base plate for depth insertion
• Convenient transport thanks to the trolley
• Slow and fast splitting speed
• Minimum tractor power of ~12 kW required (PTO 540 rpm)
Technical data
• Splitting force in t: 30
• Maximum splitting stroke in mm: 948
• Splitting material diameter in mm: 400
• Splitting length (without accessories) in mm: 1100
• Hydraulic oil capacity in l: 30
• Hydraulic stroke in MPa: 23.46
• Forward speed in cm/s: 2.4 / 8.1
• Return speed in cm/s: 4.4
• Sound pressure level in dB(A): <80
• Vibration handle in m/s2: <2.5
Net weight in kg: 333
Installation dimensions in mm: 1050x1700x2500
| Voltage | |
|---|---|
| Voltage | 400 |
| maximum splitting diameter | |
| maximum splitting diameter | 40 cm |
| maximum splitting length | |
| maximum splitting length | 110 cm |
| splitting force (tons) | |
| splitting force (tons) | 30 t |
| weight | |
| weight | 333 |
| external dimensions | |
| external dimensions | 1050 x 1700 x 2500 mm x mm x mm |
| splitting stroke adjustment | |
| splitting stroke adjustment | 94.8 cm |
| drive | |
| drive | PTO connection |
| return speed | |
| return speed | 4.4 cm/s |
| forward speed | |
| forward speed | 8.1 cm/s |
