Rain barrel fitting, 3-part - 1" x 3/4"

The set is made of weather-resistant materials that also withstand UV radiation. Permanent exposure to direct sunlight, even when the rain barrel is empty, does not pose a problem for the lifespan.

To avoid blockages from leaves or other dirt particles, it is advisable to cover the rain barrel with a leaf trap net. A regular visual inspection of the connection and, if necessary, cleaning are recommended.

Yes, the design allows for efficient integration into your garden irrigation systems. You can connect a submersible pump, provided its outlet diameter matches the 1" or 3/4" connections.

The integrated seals ensure a perfect seal. With a wooden barrel, it is important that the bore is clean and free of burrs to ensure an optimal fit of the seals.

Yes, the connections are designed for 1" x 3/4" systems. This corresponds to the most common garden hose sizes, so you can easily connect normal hoses with the usual couplings.

No, additional sealing material is not necessary. The set contains integrated seals that ensure a perfect seal and prevent water loss.

The exact thread length of the fitting is not explicitly listed in the product information. The product is designed for common rainwater barrel wall thicknesses. For very thick tank walls of IBC tanks, you should check the existing wall thickness in advance.

The threads of the set are designed for 1" x 3/4" systems. These do not fit directly on the often used S60x6 coarse threads of IBC containers. Mounting would only be possible via a separately drilled opening.

The included NBR seal is designed for a reliable seal. With correct installation in a suitable bore, no additional sealant is usually required.

The product is made of robust, weather-resistant materials. Nevertheless, the passage should be emptied over the winter and the system made frost-proof to avoid damage from freezing water.

The fitting is made of robust brass, which is very weather-resistant. The NBR seal is also suitable for outdoor use. However, in the event of permanent frost, it is recommended to empty the rain barrel to avoid damage from freezing water.

For correct and safe installation, the rain barrel should be empty before installation. This way you can drill the required hole cleanly and attach the seals optimally to ensure a perfect seal.

For the installation of this feed-through, a hole with a diameter of approximately 33 mm is recommended. This allows for secure mounting and ensures the seal with the included NBR seal.

The rain barrel fitting is designed for standard wall thicknesses and can be installed without tools. However, with very thick barrel walls, the thread length may reach its limits, which could affect the tightness and easy assembly.

Yes, the set is made of robust and weather-resistant materials and is designed for the permanent connection of a garden hose. The seals guarantee a reliable seal even if it remains connected for a longer period.

Standard irrigation controls with 3/4 inch internal thread can be connected directly to the fitting. Check in advance the exact specification of your control to see if an additional adapter is required.

The set is primarily intended for water extraction from rain barrels for garden irrigation. For pond filter applications, you should check whether the flow rate and material compatibility are sufficient for your specific requirements.

Yes, the fitting is designed for 1" x 3/4" systems. You can mount a standard faucet with a 3/4 inch connection directly on the corresponding side.

The internal thread of the fitting is G 3/4". You therefore need a faucet with a suitable external thread of size G 3/4" to create a tight seal.

Yes, the fitting is designed for integration into garden irrigation systems. You can easily connect a soaker hose to it via a suitable 3/4 inch hose.
