Screw-in heater G1 1/2, brass / V4A, without controller, 1.5kW Immersion Depth 180mm
About this item:
- Brass/V4A screw-in heater
- 1.5kW, 230/400V 3(N)~
- Immersion depth 180mm
- Stainless steel 1.4404 elements
- IP66 protection class
| Item number | WF-972857 |
| Brand | Schultze |
There are no reviews yet — yours could be the first
Share your experience with this purchase and help other customers make the right choiceThere are no questions yet
Ask a question to learn more about the product
0.0
Screw-in heaters are versatile for heating liquid media. EHK G1 1/2 with brass nipple predominantly for water and aqueous solutions.
3 tubular heating elements ø 8.5mm made of stainless steel 1.4404 hard soldered into brass nipple G1 1/2. 1500 W, 230/400 V 3(N)~, immersion depth 180 mm, surface load 10 W/cm², unheated zone 60mm. Universal version without controller, sensor empty tube ø 10x0.5mm, stainless steel connection housing IP66.
Application e.g. in washing machines, dishwashers, tempering devices, laboratory equipment. The devices are exclusively designed for industrial and commercial purposes.
Delivery with cable gland PG16, without cable. When selecting, the permissible specific surface load for the respective medium must be observed and checked on site. Not permitted for enameled containers with protective anode.
Scope of delivery: 1 x Screw-in heater G1 1/2, brass / V4A, without controller, 1.5kW Immersion Depth 180mm
| Surface load | |
|---|---|
| Surface load | 10 W/cm² |
| External dimensions | |
| External dimensions | Ø 8.5 mm |
| Variants | |
| Variants | Screw-in heater |
| Immersion depth | |
| Immersion depth | 180 mm |
| Weight | |
| Weight | 1.06 kg |
| Output power | |
| Output power | 1,500 W |
| Operating voltage | |
| Operating voltage | 230/400 3(N) V |
| Material | |
| Material | Stainless steel 1.4404 |
| Unheated zone | |
| Unheated zone | 60 mm |
| IP protection class | |
| IP protection class | IP 66 |
