Screw-in Immersion Heater G1 1/2, Brass / V4A, without Controller, 7.5kW Immersion Depth 530mm
About this item:
- Brass G1 1/2 screw-in nipple
- 7.5 kW, 400 V 3(N)~
- 530 mm immersion depth
- Stainless steel 1.4404 elements
- IP66 stainless steel housing
| Item number | WF-972862 |
| Brand | Schultze |
There are no reviews yet — yours could be the first
Share your experience with this purchase and help other customers make the right choiceThere are no questions yet
Ask a question to learn more about the product
0.0
Screw-in immersion heaters are versatile for heating liquid media. EHK G1 1/2 with brass nipple predominantly for water and aqueous solutions.
3 tubular heating elements ø 8.5mm made of stainless steel 1.4404 hard-soldered into a brass nipple G1 1/2. 7500 W, 400 V 3(N)~, immersion depth 530 mm, surface load 10 W/cm², unheated zone 60mm. Universal design without controller, sensor empty tube ø 10x0.5mm, stainless steel connection housing IP66.
Application e.g. in washing machines, dishwashers, tempering devices, laboratory equipment. The devices are designed exclusively for industrial and commercial purposes.
Supplied with cable gland PG16, without cable. When selecting, the permissible specific surface load for the respective medium must be observed and checked on site. Not permitted for enamelled containers with protective anode.
Scope of delivery: 1 x Screw-in Immersion Heater G1 1/2, Brass / V4A, without Controller, 7.5kW Immersion Depth 530mm
| External dimensions | |
|---|---|
| External dimensions | Ø 8.5 |
| Surface load | |
| Surface load | 10 W/cm² |
| Variants | |
| Variants | Screw-in heater |
| Immersion depth | |
| Immersion depth | 530 mm |
| Weight | |
| Weight | 1.53 kg |
| Material | |
| Material | Stainless steel 1.4404 |
| Operating voltage | |
| Operating voltage | 230/400 3(N) V |
| Output power | |
| Output power | 7,500 W |
| Protection class | |
| Protection class | IP 66 |
| Unheated zone | |
| Unheated zone | 60 mm |
